| Brand Name : | XinLu |
| Model Number : | Customized |
| Certification : | CO, FORM E, FORM F, SGS |
| Price : | 100$-300$/m2 |
| Delivery Time : | 5-10days according to the order quantity |
| Payment Terms : | T/T, cash, or others |
| Supply Ability : | 300000m2/month |
The wire wrapped screen panel is a type of continuous slot screen panel that is widely used in various industries such as water treatment, waste treatment, washing coal, the starch industry, and paper mills. It is designed to effectively filter and separate solid particles from liquids, making it an essential component in many industrial processes.
The wire wrapped screen panel comes in a range of slot sizes from 0.1mm to 50mm. This allows for customization depending on the specific requirements of each industry or application.
The wire wrapped screen panel is suitable for a wide range of applications including:
The wire wrapped screen panel is available in various lengths including 0.5m, 0.6m, 1m, 1.2m, 2.4m, and 3m. This allows for flexibility in installation and can be cut to the desired length to fit specific equipment or applications.
The support wire of the wire wrapped screen panel comes in different sizes including 1.8x2.5mm, 2.5x4mm, 3x4.6mm, 1.8x10mm, 2.0x10mm, and 3.0x10mm. This ensures the panel's stability and durability, even under high pressure and harsh conditions.
Etc - customized support wire sizes can also be provided to meet specific requirements.
The panel width of the wire wrapped screen panel ranges from 0.4m to 3m, providing a wide selection to fit different equipment and applications.
In addition to the standard wire wrapped screen panel, we also offer dewatering screen panels and reverse wedge wire screens. These specialized panels are designed to enhance the dewatering process and improve the efficiency of solid-liquid separation
.
The dewatering screen panel features a unique design that allows for better drainage and faster drying of materials. It is commonly used in applications such as sludge dewatering and paper pulp dewatering.
The reverse wedge wire screen is designed with a narrow V-shaped profile that provides a larger open area and higher flow capacity. This makes it ideal for applications that require high flow rates and efficient solid-liquid separation, such as in the mining and sugar industries.
With its various sizes, customizable options, and special features, the wire wrapped screen panel is a versatile and reliable choice for a wide range of industries and applications. Contact us today to learn more about how our wire wrapped screen panel can meet your specific needs.
| Technical Parameters | Values |
|---|---|
| Product Name | Wedge Wire Flat Panel |
| Alternate Name | Wire Wrapped Screen Panel, Dewatering Screen Panels, Wedge Wire Panels |
| V Wire | 1.5x2mm, 2.3x3.5mm, 2.5x4mm, 3x4.6mm, 3x5mm |
| Frame | 3x20mm, 5x20m, 4x40mm |
| Panel Width | 0.4-3m |
| Material | SS304, 316L, 321 |
| Panel Length | 0.5m, 0.6m, 1m, 1.2m, 2.4m, 3m |
| Surface Treatment | Electro-polishing |
| Support Wire | 1.8x2.5mm, 2.5x4mm, 3x4.6mm, 1.8x10mm, 2.0x10mm, 3.0x10mm, Etc |
| Slot | 0.1-50mm |
| Application | Water Treatment, Waste Treatment, Washing Coal, The Starch Industry, Paper Mill |
Are you looking for a reliable and high-quality wire wrapped screen panel for your industrial filtration needs? Look no further than XinLu Wire Mesh Products Co.,Ltd! As a leading manufacturer and supplier, we specialize in producing top-notch wire wrapped screen panels that are customized to meet your specific requirements.
Our wire wrapped screen panel, also known as flat V wire panel, Johson wire flat panel, wedge wire flat panel, is made of high-quality stainless steel or carbon steel wire. The unique design of the panel with V-shaped profile wires and support rods ensures excellent filtration performance and durability.
Our wire wrapped screen panel is widely used in various industries, including:
It is suitable for both liquid and solid filtration, making it the perfect solution for all your industrial filtration needs.
Don't settle for subpar wire wrapped screen panels, choose XinLu Wire Mesh Products Co.,Ltd for the best quality and service. Contact us now to get a quote and place your order!
Brand Name: XinLu
Model Number: Customized
Place of Origin: Anping County Xinlu Wire Mesh Products Co.,Ltd
Certification: CO, FORM E, FORM F, SGS
Minimum Order Quantity: 3m 2
Price: 100$-300$/m 2
Packaging Details: Pallet, wooden box
Delivery Time: 5-10 days according to the order quantity
Payment Terms: T/T, cash, or others
Supply Ability: 300000m 2 /month
Frame: 3x20mm, 5x20m, 4x40mm
Support Wire: 1.8x2.5mm, 2.5x4mm, 3x4.6mm, 1.8x10mm, 2.0x10mm, 3.0x10mm, Etc
Material: SS304, 316L, 321
V Wire: 1.5x2mm, 2.3x3.5mm, 2.5x4mm, 3x4.6mm, 3x5mm
Surface Treatment: Electro-polishing
At XinLu, we understand that every customer has unique needs and preferences. That's why we offer customized services for our wire wrapped screen panel product. As a leading manufacturer and supplier of wire mesh products, we are committed to providing high-quality solutions that meet your specific requirements.
Our wire wrapped screen panel, also known as wire wrapped Johnson screen plate, is designed for various industrial applications. With our advanced technology and expertise, we can customize the size, shape, and material of the screen panel to fit your needs.
As a testament to our dedication to quality, our products are certified with CO, FORM E, FORM F, and SGS. We have a minimum order quantity of 3m 2 , and our price ranges from 100$-300$/m 2 . We ensure safe transportation by packaging the panels in pallets or wooden boxes.
We understand the importance of time in your business, which is why we guarantee a delivery time of 5-10 days, depending on the order quantity. Our payment terms are flexible, and we accept T/T, cash, or other forms of payment.
With a supply ability of 300000m 2 /month, we can cater to your bulk orders efficiently. Our frames are available in 3x20mm, 5x20m, and 4x40mm sizes, while our support wires come in various sizes such as 1.8x2.5mm, 2.5x4mm, 3x4.6mm, 1.8x10mm, 2.0x10mm, and 3.0x10mm.
We use high-quality materials such as SS304, 316L, and 321 for superior durability and corrosion resistance. Our V wires are available in sizes of 1.5x2mm, 2.3x3.5mm, 2.5x4mm, 3x4.6mm, and 3x5mm to cater to a wide range of applications.
To ensure a smooth and polished finish, we offer electro-polishing as a surface treatment option for our wire wrapped screen panels. This not only enhances the appearance of the product but also improves its resistance to corrosion.
Choose XinLu for a customized wire wrapped screen panel that meets your exact specifications and delivers exceptional performance. Contact us now to discuss your requirements and get a quote.
|
|
