the wedge wire screen, This type of mesh is made of metal wire and is shaped like a vee, triangle, or trapezoid. It is commonly used for sieving and filtering purposes in a variety of industries. Its strong and durable design allows it to withstand high capacity applications and it can be easily molded into different shapes for various screening and filtering needs.
The materials used to construct wedge wire screens include stainless steel wire (such as SS205B, 304, or 316) and low carbon galvanized wire (LCG), as well as mild steel wire and iron wire.
The shape of wedge wire screens can vary, with common forms including tube/pipe (also known as wire-wrapped stainless steel screen pipes, water and oil well screens, changeable filter elements, screen cylinders, spiral screen pipes, strainer tubes, filter circumferences, filter drums, v wire slot tubes, screen baskets, cylinder screens, stainless steel lateral arms, hub laterals, and head laterals), nozzles (such as water filter nozzles, Johnson wire screen nozzles, and stainless steel strainer nozzles), screen plates/pieces/flat panels (such as dewatering screen panels, Johnson screen plates, v wire flat panels, wire wrapped panels, sieve bends for coal, arc screen plates, vibrating screen plates, plates with polyurethane frames, curved screens, and wedge wire gratings), and cylinders (such as rotary drum screens, DSM screens, and wedge wire filter baskets).
Wedge wire screens are created through a full welded weaving process, ensuring their strength and durability.
These screens have a wide range of uses, including in the water well, oil, mining, coal, chemical, fertilizer, food, environmental protection, sewage treatment, and salt industries. They can be used for sewing, oil filtering, and wire nets in salt production, among other applications.
Slots that open inward (referred to as FOTI) serve as a barrier to prevent sand from becoming stuck in the screen. This feature is especially helpful in applications where sand is present.
The design of our wedge wire screens ensures minimal pressure drop while maintaining a stable flow rate. This results in more efficient pumping and a longer life for oil wells.
Our screens also boast high efficiency, guaranteeing consistent performance and extended life for oil wells.
This is all possible thanks to our continuous slot wedge wire, which provides a larger open area compared to perforated metal pipes or slotted pipes commonly used in water well applications.
Furthermore, our sturdy longitudinal support rods offer excellent resistance to pressure.
Our customization support allows for the selection of the perfect wedge wire screen tube to suit your specific application and filtration needs.
We take pride in the precise filtration performance of our screens, achieved through the use of state-of-the-art equipment that ensures precise slot sizes and a high level of roundness for the screen tube.
We offer various types of wedge wire screens, including different edge types and diameters, to cater to a wide range of industries such as water treatment, oil and gas, food and beverage, and mining.
Quality is of the utmost importance to us, which is why we use surface pickling and passivation treatment to ensure top-quality finished products.
| Support Shape | V Wire, Round Wire, Support Bar |
|---|---|
| Screen Plate Shape | Wedge Wire Flat Panel, Sieve Bend Screen, Wedge Wire Garting |
| Strength | High Mechanical Strength |
| Profile Wire | #63 (1.5*2.5mm), #93 (2.3*3.5mm), #118 (3.0*4.6mm), Etc |
| Wire Shape | V Shape, Wedge Wire Shape, Round Wire Shape |
| End Connection | Threaded, Welded Rings, Flange |
| Surface Treatment | Polishing, Galvanized |
| Key Words | Wedge Wire Screen, V Wire Screen, Johnson Wire Screen, Mine Screen Mesh |
| Screen Nozzle Shape | Single-head Filter Nozzle, Double-head Filter Nozle, Long-handle Filter Nozzle, Flat Plate Flow Rating Type Filter Nozzle |
| Material | Low Carbon Steel, Iron, Mild Steel, Stainless Steel (SS-205, 304, 316, 904L, 2205, 2507, C276 Or Other Metal Wire, Etc) |
| Key Words | Wedge Wire Filter Candle, Johnson Type Wedge Wire Screen, Wedge Wire Screen Cylinder, Stainless Steel Screen Filter, Johnson Wire Mesh |
|---|---|
| Support Shape | V Wire, Round Wire, Support Bar |
| Screen Plate Shape | Wedge Wire Flat Panel, Sieve Bend Screen, Wedge Wire Garting |
| Strength | High Mechanical Strength |
| Profile Wire | #63 (1.5*2.5mm), #93 (2.3*3.5mm), #118 (3.0*4.6mm), Etc |
| Wire Shape | V Shape, Wedge Wire Shape, Round Wire Shape |
| End Connection | Threaded, Welded Rings, Flange |
| Surface Treatment | Polishing, Galvanized |
| Screen Nozzle Shape | Single-head Filter Nozzle, Double-head Filter Nozle, Long-handle Filter Nozzle, Flat Plate Flow Rating Type Filter Nozzle |
| Material | Low Carbon Steel, Iron, Mild Steel, Stainless Steel (SS-205, 304, 316, 904L, 2205, 2507, C276 Or Other Metal Wire, Etc) |
The oil and gas industry relies on several types of well screens for various purposes, such as deep vertical wells, supply wells, driven/jetted point wells, and drilled wells. These screens are designed to prevent debris and impurities from entering the well and damaging the equipment. Additionally, high flow municipal wells, as well as domestic water wells for residences and farms, require efficient well screens to ensure a steady and clean water supply.
To remove impurities from water used in the petrochemical industry, filtration systems equipped with sand and carbon filters, as well as condensate polishers and ion exchange systems, are necessary. These systems also play a crucial role in clarifying water, underdraining for media filtration, and seawater desalination. They are commonly used in thermal power plants for effective water treatment.
Other applications of well screens include vibrating screen decking, surface water intake screens, fish diversion screen panels, and grain drying screens. In construction, wedge wire screens are used for various purposes, while sieve bends, cylindrical screens, centrifugal baskets, DEM screens, and pressure screens are essential components in the mineral and aggregate processing industry.
In the petrochemical and refining industries, center pipes, outer baskets, distributor trays, nozzle systems, and scale traps are just some of the equipment that utilize well screens. Likewise, the pulp and paper industry relies on screen baskets, extraction plates, filtrate cleaning, fiber recovery, and refurbishing services for efficient filtration and separation processes.
Brand Name: Xinlu
Model Number: Customized 1" - 40"
Place of Origin: Anping County Xinlu Wire Mesh Produts Co.,Ltd
Certification: CO, FORM E, FORM F, SGS
Minimum Order Quantity: 10pcs
Packaging Details: inside transparent plastic bag, outside woven bag, or bubble bag, or wooden box, or pallet
Delivery Time: 5-20days according to the order quantity
Payment Terms: T/T, cash, or others
Wire Shape: V Shape, Wedge Wire Shape, Round Wire Shape
Support shape: V Wire, Round Wire, Support Bar
Strength: High Mechanical Strength
Profile Wire: #63 (1.5*2.5mm), #93 (2.3*3.5mm), #118 (3.0*4.6mm), Etc
Each Johnson type screen mesh is carefully packaged to ensure its safe delivery. We use high-quality wooden cases or cartons to protect the product from damage during transportation. Additionally, we also offer custom packaging options to meet specific customer requirements.
For shipping, we work with trusted and efficient logistics companies to deliver the product to our customers. We offer flexible shipping options, including air, sea, and land transportation, to meet the needs of our customers worldwide. Our team also takes great care in tracking the shipment and providing timely updates to ensure a smooth delivery process.
Common Specifications of Stainless Steel Wedge Wire Water Well Screens | |||||||
|---|---|---|---|---|---|---|---|
Size (inch) | O.D. (mm) | Slot Size (mm) | Length (m) | Collapse Strength (Bar) | Tensile Weight (ton) | Profile Wire (Width × Height) (mm) | Support Rods (mm) |
| 3-1/2 | 88.9 | 1.0 | 2.9 | >22 | 10.2 | 2.3 × 3.5 | 3.8 mm / 22 |
| 4-1/2 | 114.3 | 1.0 | 2.9 | >28 | 11.5 | 2.3 × 3.5 | 3.8 mm / 22 |
| 6-5/8 | 168.3 | 0.75 | 5.8 | >40 | 12.8 | 2.3 × 3.5 | 3.8 mm / 32 |
| 6-5/8 | 168.3 | 1.0 | 5.8 | >33 | 12.8 | 2.3 × 3.5 | 3.8 mm / 32 |
| 6-5/8 | 168.3 | 0.63 | 5.8 | >83 | 45 | 3.2 × 6.0 | 6.0 mm*32 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | >34 | 21.9 | 2.3 × 3.5 | 3.8 mm / 48 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | >50 | 38.2 | 3.0 × 5.0 | 4.0 mm / 48 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | >60 | 46 | 3.2 × 6.0 | 5.0 mm / 48 |
| 10-3/4 | 273.1 | 0.75 | 5.8 | >50 | 32.9 | 2.3 × 3.5 | 4.9 mm / 55 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | >60 | 39.5 | 3.0 × 5.0 | 4.9 mm / 55 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | >100 | 48 | 3.2 × 6.0 | 5.0 mm / 55 |
| 12-3/4 | 323.9 | 1.0 | 5.8 | >120 | 37.2 | 3.0 × 5.0 | 4.0 mm / 50 |
| 14 | 355.6 | 1.0 | 2.9 | >80 | 37.8 | 3.0 × 5.0 | 4.0 mm / 59 |
|
|
