Feiya International Group Ltd Anping Branch Factory---Xinlu Wire Mesh Products Co.,ltd ROTARY DRUM SCREENS

Feiya International Group Ltd Anping Branch Factory---Xinlu Wire Mesh Products Co.,ltd Screens Rotary drum screens are energy efficient screening devices that are very effective in treatment applications that are high in grit and sand loads with variable flows and solid concentrations. These screens are also good at removing hairs, and fibrous materials that can wreck havoc on important downstream treatment processes such as membrane bioreactors.

Removing these materials during preliminary treatment minimizes the chances of the plants performance being compromised and increases the chances that subsequent treatment processes are trouble and maintenance free.

Drum screens offer some provisions that are typically not available on other micro and/or fine screens. This device combines screening, washing, compacting, and dewatering all in one unit. By combining these four operations, equipment and operation costs are greatly reduced.

For this type of fine screen, the screening medium is attached to a cylinder that rotates the flow regime. The construction of a the drum screen will depend on the direction of flow through the screen media. Either flow will enter through one end of the drum and out through the screen with debris being captured on the interior surface, or flow will enter the top of the unit and pass through with solids capture on the exterior.

Rotary drum screens that are fed internally have flow capacities that range from 0.03 to 0.8 m3/s or (0.7 to 19 mgd) per screen

While drum screens that are fed externally have a capacity of less than 0.13 m3/s or (3 mgd). Sizes of drum screen varies from 0.9 to 2m or (3 to 6.6 ft) diameter and lengths from 1.2 to 4 m or (4 to 13.3 ft)

As the flow makes its way through the unit, screened water continuous on to the next process. While collected screenings are transported by the gyration of the drum screen toward the discharge chute where additional dewatering occurs. After dewatering, screenings are dumped into a container where they are stored for future disposal. As the drum screen rotates, the screen is scoured clean by a water jet stream.

Advantage:
High flow rates
Non-clogging slot
Reduction cost in operating

Data reference table:

Any inquiry please don't hesitate to contact us !(whatsApp+86-13315867171)

Hope we can work together soon.

Contact:feiyatrade@hotmail.com

Skype: terastar.lee

---------------------------------------------------------------------------------------------------------------

Our factory Xinlu Wire Mesh product co., Ltd located in Anping country, Hebei Province, China.

Our mainly products are: stainless steel vee sharped wire / wrap wire, johnson wire screeen, water well screen / rod based wire wrapped screen, wedge wire screen, reverse wedge wire screen, stainess steel strainer pipe, v wire slot tube, perfect roundness well screen pipe, dewatering well screen, dewatering screen panel, wedge wire grating, v wire flat panel, screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, wedge wire support grids, sieve bend plate, v wire screens, ARC screen, filter bottom nozzle, stainless steel lateral screens, wedge wire filter candles, Rotary drum screens, strainer cylinder, sand control well screen, oil well screen, rod basedc ontinuous slot screens, header and hub laterals & hub radial laterals etc.

Anping County Xinlu Wire Mesh Products Co., Ltd is situated in Anping county, renowned as "The hometown of wire mesh in China". Established in 1997, our company boasts a rich history and a large-scale production capacity. We are proud to be certified by the ISO9000 quality system authentication.

At Xinlu Wire Mesh, we specialize in the production of a wide range of wire mesh products. Our offerings include horsetail hair, V-shaped wire welded stainless steel screens, low carbon steel screens, Johnson Specialty screens, water well screen, well screen pipe, wire wrapped screen pipes, welded wedge wire screens, johnson wire screen tube, johnson wire screen pipe, johnson wire screen panel, johnson wire screen plate, johnson wire cylinder screen, johnson wire filter nozzle, reverse rolled screen tubes, weedge wire screen cylinders, v wire slot screens, sand control well screens, water filter nozzle, Johnson wire screen nozzles, water and gas strainers, weedge wire filter elements, Sieve bend screen, wedge wire sieve bends, arc screen plates, wire wrapped screen panels, flat wedge wire panels with frames, vibrating sieve screens, wire wrapped liners, chain link fences, fence netting, welded wire meshes, stainless steel wire meshes, galvanized wires, galvanized wire meshes, crimped wire meshes, Gabion meshes, welded Gabion boxes, PVC coated Gabions, wire mesh panels, stainless steel wire meshes, steel wires, water and gas filter meshes, filter tubes, and other wire mesh products. Additionally, we also offer mesh belt conveyors, window screening series, and metal jewelry products.

Our products find applications in various industries such as drilling wells and pumps, ore selection, petroleum, chemical, electronics, transportation, plastics, food, architecture, traffic, musical instruments, safety, and more. Not only are our products highly sought after in China, but they are also well-received in African countries, the Middle East, and Southeast Asia.
