Spiral Wedge Wire Johnson Well Screen Tube with Threaded Male and Female End Connections

Product Introduction:

Anping County Xinlu Wire Mesh Products Co., Ltd presents our Spiral Wedge Wire Johnson Well Screen Tube, designed for exceptional filtration in water wells. These tubes are crafted from premium stainless steel materials, ensuring durability and resistance to corrosion, making them suitable for various water well operations.

Key Features:

• Material: Stainless Steel 304, 316L, Non-magnetic SS, Low Carbon Galvanized, Duplex Steel, and more.
• Diameter: Available from 29mm to 800mm, with standard sizes listed in our product catalog.
• Slot Size: Ranging from 0.1mm to 100mm, with standard options at 0.5mm, 0.63mm, 0.75mm, 1.0mm, and 1.5mm.
• Length: Customizable up to 6000mm, with standard lengths of 2.95m and 5.85m to fit containers.
• End Connections: Options include Welded Rings, Plain Beveled Ends, and Threaded Ends (API STC, PT NPT, BSP, G), as well as Flanges.

Advantages:

• High Open Area: The V-wire design provides a large open area for reduced flow resistance and improved water removal efficiency.
• Non-clogging: The V-shaped wire structure minimizes the risk of clogging, ensuring consistent filtration performance.
• High Strength: Welded from stainless steel wire, these tubes are built to withstand high water pressure and heavy loads.
• Temperature Adaptability: Suitable for a wide range of temperatures, making them ideal for various environments.
• Adjustable Clearance: The slot size can be customized to meet different filtration needs without incurring additional costs.

ANPING COUNTY XINLU WIRE MESH PRODUCTS CO.,LTD WEDGE WIRE SCREEN CYLINDERSMADE FROM VEE SHAPED WIRE

Xinlu Wire Mesh Products Co.,Ltd Screens make Screen Cylinders from vee shaped wire for filtration. A V shaped wire is spirally wound and welded on a cage of longitudinal wedge shaped or trapezoidal shaped rods. Each and every intersection between vee shaped wire and the wedge wire is welded automatically. This creates a continuous spiral slot. These screen tubes cylinders are also known as continuous vee slot tubes.

Different types of construction are available such as

Rod base construction : Outside to Inside Flow

Wire Base Construction : Inside to Outside flow

Inverted Wire Base : Inside to Outside flow

External Axial Wire : Outside to Inside Flow

Internal Axial Wire : Inside to Outside Flow

External Circumferential Wire : Outside to Inside Flow

Internal Circumferential Wire : Inside to Outside Flow

Advantages:

• High Open Area: The V-wire design provides a large open area for reduced flow resistance and improved water removal efficiency.
• Non-clogging: The V-shaped wire structure minimizes the risk of clogging, ensuring consistent filtration performance.
• High Strength: Welded from stainless steel wire, these tubes are built to withstand high water pressure and heavy loads.
• Temperature Adaptability: Suitable for a wide range of temperatures, making them ideal for various environments.
• Adjustable Clearance: The slot size can be customized to meet different filtration needs without incurring additional costs.

Applications:

Our Johnson Well Screen Tubes are versatile and can be used in:

• Water wells
• Wastewater treatment
• Water supply systems
• Coal & mining
• Food & beverage filtration
• Environmental protection
• Refining & petrochemical
• Architecture & construction

Customization and Quality Assurance:

We offer customization services to meet your specific filtration needs. With a minimum order quantity of 10pcs and competitive pricing, we ensure that your requirements are met with precision and quality. Our commitment to quality includes:

1. Dedicated Quality Control: Each production process is monitored by specialized personnel.
2. Professional Engineering Review: Our engineers conduct thorough quality checks to ensure product excellence.

Frequently Asked Questions:

Q1: Can I have a sample order?
A: Yes, we welcome sample orders to test and check quality.

Q2: What about the lead time?
A: 3-5 days for sample preparation, 15-25 working days for mass production.

Q3: Do you have any MOQ limit for the order?
A: Low MOQ, with 3pcs available for sample checking.

Q4: How do you ship the goods and how long does it take to arrive?
A: We offer various shipping options, including express shipping which takes 5-7 days.

Q5: How to proceed an order?
A: Share your specifications, receive a quote, confirm and place a deposit, and we will arrange production.

Q6: Is it OK to print my logo on the product?
A: Yes, please inform us before production for logo printing.

About Anping County Xinlu Wire Mesh Products Co., Ltd:

As a leading manufacturer of wedge wire screen mesh products, we are committed to delivering innovative and high-quality filtration solutions. Our focus on customer satisfaction and product excellence ensures that you receive the best products and services in the industry.

Data reference table:

---------------------------------------------------------------------------------------------------------------

Our factory Xinlu Wire Mesh product co., Ltd located in Anping country, Hebei Province, China.

Our mainly products are: stainless steel vee sharped wire / wrap wire, johnson screeen, water well screen / rod based wire wrapped screen, wedge wire screen, reverse wedge wire screen, stainess steel strainer pipe, v wire slot tube, perfect roundness well screen pipe, dewatering well screen, dewatering screen panel, wedge wire grating, v wire flat panel, screen nozzle, water and gas strainer nozzle, stainless steel filter nozzle, wedge wire support grids, sieve bend plate, v wire screens, ARC screen, filter bottom nozzle, stainless steel lateral screens, wedge wire filter candles, Rotary drum screens, strainer cylinder, sand control well screen, oil well screen, rod basedc ontinuous slot screens, header and hub laterals & hub radial laterals etc.

Anping County Xinlu Wire Mesh Products Co., Ltd is situated in Anping county, renowned as "The hometown of wire mesh in China". Established in 1997, our company boasts a rich history and a large-scale production capacity. We are proud to be certified by the ISO9000 quality system authentication.

At Xinlu Wire Mesh, we specialize in the production of a wide range of wire mesh products. Our offerings include horsetail hair, V-shaped wire welded stainless steel screens, low carbon steel screens, Johnson Specialty screens, water well screen, well screen pipe, wire wrapped screen pipes, welded wedge wire screens, johnson wire screen tube, johnson wire screen pipe, johnson wire screen panel, johnson wire screen plate, johnson wire cylinder screen, johnson wire filter nozzle, reverse rolled screen tubes, weedge wire screen cylinders, v wire slot screens, sand control well screens, water filter nozzle, Johnson wire screen nozzles, water and gas strainers, weedge wire filter elements, Sieve bend screen, wedge wire sieve bends, arc screen plates, wire wrapped screen panels, flat wedge wire panels with frames, vibrating sieve screens, wire wrapped liners, chain link fences, fence netting, welded wire meshes, stainless steel wire meshes, galvanized wires, galvanized wire meshes, crimped wire meshes, Gabion meshes, welded Gabion boxes, PVC coated Gabions, wire mesh panels, stainless steel wire meshes, steel wires, water and gas filter meshes, filter tubes, and other wire mesh products. Additionally, we also offer mesh belt conveyors, window screening series, and metal jewelry products.

Our products find applications in various industries such as drilling wells and pumps, ore selection, petroleum, chemical, electronics, transportation, plastics, food, architecture, traffic, musical instruments, safety, and more. Not only are our products highly sought after in China, but they are also well-received in African countries, the Middle East, and Southeast Asia.
